Tagelus TA 60D Sand Filter⁚ A Comprehensive Guide

This comprehensive guide provides a detailed overview of the Tagelus TA 60D sand filter, covering its key features, installation, operation, maintenance, and troubleshooting.

Introduction

The Pentair Tagelus TA 60D Sand Filter is a vital component of any swimming pool filtration system, designed to remove impurities and debris from the water, ensuring a clean and refreshing swimming experience. This comprehensive guide will equip you with the necessary knowledge to install, operate, and maintain your Tagelus TA 60D sand filter effectively. From understanding its key features and benefits to navigating troubleshooting procedures, this manual serves as your ultimate resource for maximizing the performance and longevity of your filter.

The Tagelus TA 60D stands out with its durable fiberglass-reinforced tank, ensuring robust construction and long-lasting performance. It incorporates a six-position, top-mounted multiport valve for convenient control over various filtration functions. Its innovative ClearPro technology goes beyond traditional sand filters, removing particles up to five times smaller, delivering crystal-clear water that exceeds visual clarity.

Key Features and Benefits

The Tagelus TA 60D Sand Filter is packed with features designed to enhance filtration efficiency, simplify operation, and ensure long-lasting performance. Here are some key highlights⁚

• ClearPro Technology⁚ This advanced technology sets the Tagelus TA 60D apart by removing particles up to five times smaller than traditional sand filters, resulting in exceptionally clear pool water.
• Six-Position Multiport Valve⁚ The top-mounted multiport valve provides easy access to a range of functions, including filter, backwash, rinse, circulate, closed, and waste, allowing you to optimize your filter’s performance for various needs.
• Durable Fiberglass Tank⁚ The one-piece fiberglass-reinforced tank construction ensures superior strength and resistance to corrosion, ensuring long-lasting performance and reliability.
• Combination Water and Sand Drain⁚ This feature simplifies servicing and winterizing by combining both water and sand drains, making the process fast and efficient.
• Special Lateral Design⁚ The unique lateral design optimizes flow characteristics, leading to longer filter cycles and reduced operating costs.
• Maximum Operating Pressure⁚ With a maximum operating pressure of 50 psi, the TA 60D can handle a wide range of pool pump pressures.

These features contribute to the Tagelus TA 60D’s exceptional performance, making it a reliable and efficient choice for maintaining crystal-clear pool water.

Installation

Installing the Tagelus TA 60D sand filter is a straightforward process that can be completed with basic tools and a few steps. Here’s a general overview of the installation process⁚

1. Choose a Suitable Location⁚ Select a level, stable surface for your filter, ensuring it’s easily accessible for maintenance and operation. Consider proximity to your pool pump and plumbing connections.
2. Prepare the Base⁚ If needed, create a firm and level foundation for the filter. You may need to use concrete blocks or a leveled sand bed for stability.
3. Assemble the Filter Tank⁚ Carefully assemble the tank components, ensuring all parts are properly aligned and secured. Follow the manufacturer’s instructions for specific details.
4. Install the Sand Guide⁚ Place the sand guide within the tank as instructed by the manufacturer. This component helps evenly distribute the filter sand.
5. Add Filter Media⁚ Fill the tank about half full with water, then slowly add the specified amount of filter sand, taking care not to damage the laterals.
6. Install the Multiport Valve⁚ Assemble the multiport valve to the top of the filter tank, ensuring a secure and leak-free connection.
7. Connect Piping⁚ Connect the inlet and outlet piping from your pool pump to the filter, ensuring a secure connection.
8. Prime the System⁚ Once the filter is assembled, prime the system by filling it with water and removing any air pockets.

Remember to refer to the specific instructions provided in your Tagelus TA 60D manual for detailed guidance and safety precautions during the installation process.

3.1. Parts List

The Tagelus TA 60D sand filter comes with a comprehensive set of components designed for efficient filtration. Here’s a typical parts list for the TA 60D model⁚

• Filter Tank⁚ A durable fiberglass-reinforced tank with one-piece construction, providing strength and resistance to corrosion.
• Laterals⁚ Internal components that distribute water evenly through the filter sand, maximizing filtration efficiency.
• Multiport Valve⁚ A six-position valve that controls the flow of water through the filter, allowing for various functions like filtering, backwashing, and rinsing.
• Sand Guide⁚ A component that helps ensure even distribution of filter sand within the tank, preventing channeling and maximizing filtration.
• Pressure Gauge⁚ A gauge that displays the pressure within the filter, indicating the need for backwashing when pressure rises beyond a certain point.
• Air Relief Valve⁚ A valve that releases trapped air from the filter, preventing air pockets from interfering with filtration.
• Sand⁚ The primary filtration medium, typically composed of silica sand with a specific grain size for optimal filtration.
• Optional Accessories⁚ Depending on your specific needs, additional accessories may be available, such as a timer, automatic backwash system, or winterizing kit.

It’s important to confirm the exact parts list included with your specific TA 60D model by referring to the user manual or contacting the manufacturer.

3.2. Assembly Process

The assembly of the Tagelus TA 60D sand filter involves a series of steps that ensure proper installation and optimal performance. Here’s a general overview of the assembly process⁚

1. Locate the Filter⁚ Choose a suitable location for the filter, ensuring it’s level and easily accessible for maintenance. Avoid placing the filter in direct sunlight or extreme temperatures.
2. Install the Sand Guide⁚ Insert the sand guide into the top of the filter tank, ensuring it’s properly positioned and secured.
3. Add Water⁚ Partially fill the tank with water, about half full, to provide support for the sand during the next step.
4. Add Sand⁚ Slowly pour the specified amount of filter sand into the tank, ensuring even distribution to avoid channeling.
5. Remove Sand Guide⁚ Carefully remove the sand guide once the sand is in place.
6. Install the Multiport Valve⁚ Attach the multiport valve to the top of the filter tank and tighten it securely with the clamp ring.
7. Connect Piping⁚ Attach the inlet and outlet piping to the multiport valve according to the manufacturer’s instructions. Ensure all connections are tight and secure.
8. Install Pressure Gauge and Air Relief Valve⁚ Connect the pressure gauge and air relief valve to the appropriate locations on the filter tank, following the manufacturer’s instructions.

Remember, this is a general assembly process. Always refer to the specific installation instructions provided with your Tagelus TA 60D sand filter for detailed guidance.

3.3. Connecting Piping

Connecting the piping to the Tagelus TA 60D sand filter is a crucial step in the installation process. This section outlines the key steps involved, ensuring proper water flow and system functionality⁚

1. Identify Inlet and Outlet⁚ Locate the inlet and outlet ports on the multiport valve. The inlet port is typically marked with an “IN” or “I” symbol, while the outlet port is marked with an “OUT” or “O” symbol.
2. Prepare Piping⁚ Ensure the inlet and outlet pipes are cut to the correct length, allowing for easy connection to the filter and the rest of your pool system.
3. Connect Inlet Pipe⁚ Attach the inlet pipe to the inlet port on the multiport valve. Use appropriate plumbing fittings, such as unions or threaded adapters, to ensure a secure and leak-proof connection.
4. Connect Outlet Pipe⁚ Attach the outlet pipe to the outlet port on the multiport valve. Use the same type of fittings as used for the inlet pipe.
5. Tighten Connections⁚ Ensure all pipe connections are securely tightened. Use a wrench or pipe pliers to achieve a snug fit without overtightening, which could damage the fittings.
6. Inspect for Leaks⁚ Once all connections are made, thoroughly inspect for any leaks. If leaks are present, tighten the connections further or use pipe sealant if necessary.

Always refer to the manufacturer’s instructions for specific recommendations on pipe sizes and fitting types for your Tagelus TA 60D sand filter.

Operation

The Tagelus TA 60D sand filter is designed for efficient operation, providing clean and sparkling pool water. This section outlines the key operational aspects, ensuring you maximize its performance and longevity⁚

• Initial Startup⁚ Before starting the filter, ensure the multiport valve is set to the “Filter” position. Start the pool pump and allow the water to circulate through the filter for a few minutes. This initial run helps to prime the filter and remove any air trapped in the system.
• Pressure Gauge Monitoring⁚ Regularly monitor the pressure gauge on the filter. The pressure reading should be within the manufacturer’s recommended range, typically between 10 and 25 PSI. A significant increase in pressure indicates a dirty filter that needs backwashing.
• Backwashing Schedule⁚ Backwashing the filter is essential for removing accumulated debris and maintaining proper filtration. The frequency of backwashing depends on factors like pool usage, water clarity, and the type of filter media. A typical backwashing schedule is every 7 to 14 days.
• Rinse Cycle⁚ After backwashing, run the filter through a rinse cycle to remove any remaining debris and restore proper water flow. This cycle typically lasts for a few minutes.
• Regular Maintenance⁚ Performing routine maintenance tasks like inspecting the filter tank for leaks, checking the multiport valve for proper operation, and inspecting the filter media for wear or damage will help to ensure optimal filter performance.

Always refer to the manufacturer’s instructions for specific recommendations on operating procedures, backwashing intervals, and maintenance schedules for your Tagelus TA 60D sand filter.

4.1. Multiport Valve Settings

The multiport valve is the control center of your Tagelus TA 60D sand filter, enabling you to perform different functions. Understanding its settings is crucial for maintaining optimal filter performance and extending its lifespan. Here’s a breakdown of the common settings and their functions⁚

• Filter⁚ The primary setting for normal operation, allowing water to flow through the filter media, capturing debris and impurities.
• Backwash⁚ This setting reverses the flow of water, dislodging dirt and debris from the filter media and sending it to waste.
• Rinse⁚ This setting helps to clear any remaining debris from the filter media after backwashing, ensuring clean and efficient filtration.
• Circulate⁚ This setting allows water to bypass the filter, circulating it directly back to the pool. This is useful for quickly raising the water temperature or during winterization.
• Waste⁚ This setting allows water to be drained directly to waste, which is helpful for removing excess water from the pool or during winterization.
• Closed⁚ This setting isolates the filter from the pool system, stopping water flow. This is usually used for maintenance or repairs.

Remember to familiarize yourself with the specific positions and functions of the multiport valve on your Tagelus TA 60D sand filter. Always refer to the manufacturer’s instructions for detailed information on each setting and how to use them correctly.

4.2. Backwashing Procedure

Backwashing is a crucial part of maintaining a clean and efficient sand filter. This process effectively removes accumulated dirt and debris from the filter media, ensuring optimal water clarity and preventing clogging. Here’s a step-by-step guide on how to backwash your Tagelus TA 60D sand filter⁚

1. Turn off the pool pump⁚ Ensure the pump is completely off before proceeding with the backwashing procedure.
2. Set the multiport valve to “Backwash”⁚ Rotate the valve handle to the “Backwash” position, allowing the water to flow in reverse direction.
3. Monitor the waste line⁚ Observe the waste line for a clear, consistent flow of water, indicating that the backwashing process is working correctly.
4. Allow for backwashing⁚ Continue the backwashing process for a few minutes, typically 2-5 minutes, until the water runs clear. This ensures the filter media is thoroughly cleansed.
5. Switch to “Rinse”⁚ After backwashing, rotate the valve handle to the “Rinse” position, allowing a brief rinse to clear any remaining debris from the filter media.
6. Return to “Filter”⁚ Once the rinse cycle is complete, rotate the valve handle back to the “Filter” position, resuming normal filtration operation.
7. Restart the pool pump⁚ After the valve is back in the “Filter” position, turn on the pool pump and monitor the pressure gauge for a normal reading.

Regular backwashing, typically once a week or as needed, is essential for maintaining optimal filter performance. Always refer to your Tagelus TA 60D sand filter’s manual for specific recommendations on backwashing frequency based on your pool’s usage and water conditions.

4.3. Troubleshooting

While the Tagelus TA 60D sand filter is designed for reliable operation, occasional issues may arise. Addressing these promptly ensures optimal performance and prevents potential problems. Here are common troubleshooting steps for resolving issues with your Tagelus TA 60D sand filter⁚

• High Pressure Gauge Reading⁚ If the pressure gauge reading exceeds the normal operating range (typically 10-25 psi), it indicates a clogged filter. Backwash the filter according to the procedure outlined in section 4.2. If the pressure remains high, inspect the filter media for excessive dirt accumulation or compaction.
• Low Pressure Gauge Reading⁚ A low pressure reading may indicate a leak in the filter tank, piping, or valve. Carefully inspect all connections and fittings for leaks. If a leak is identified, repair it immediately to prevent further water loss and ensure proper filtration.
• Water Flow Issues⁚ If you experience reduced water flow or a complete stoppage, check for obstructions in the filter tank, laterals, or piping. Ensure the multiport valve is set to the correct position and is operating smoothly.
• Air in the System⁚ If air bubbles are present in the water flow, bleed the air from the system by opening the air relief valve on the filter tank. This will allow trapped air to escape, restoring proper water circulation.

If you encounter persistent issues or are unsure about troubleshooting steps, consult the Tagelus TA 60D sand filter manual or contact a qualified pool professional for assistance.
